Trane/American Standard
Air-Handler Base
Trane/American Standard Air-Handler Base
- Category:Air Handler Base
- Material:Galvanized Steel
- Specification Sheet: Download PDF
- Purchase: Find Distributors
Product Description
Fully powder coated to give a long lasting corrosion resistance and longevity.
Galvanized steel provides excellent corrosion resistance and longevity.
Plastic capped feet to protect foundation surface.
Pre-filter track accommodates a 1" thick air-filter (filter not included).
Stands individually boxed for easy inventory.
Product Construction
Frame:
16 gauge 1" X 1" square tube.
16 gauge 1" X 1" steel angle.
20 gauge 1/2" X 1/2" steel angle
Outside Casing:
16 gauge ASTM A-653 hot-dipped galvanized steel sheet.
26 gauge ASTM A-653 hot-dipped galvanized steel sheet.
Mesh:
13 gauge 1-3/4" X 3/4" expanded steel.
16 gauge 1" X 1" square tube.
16 gauge 1" X 1" steel angle.
20 gauge 1/2" X 1/2" steel angle
Outside Casing:
16 gauge ASTM A-653 hot-dipped galvanized steel sheet.
26 gauge ASTM A-653 hot-dipped galvanized steel sheet.
Mesh:
13 gauge 1-3/4" X 3/4" expanded steel.
Standard Sizes
| Part No. | Depth | Width | Height | Quantity |
|---|---|---|---|---|
| TASB175 | 21" | 17-5/8" | 17-1/4" | 1 |
| TASB215 | 21" | 21-5/8" | 17-1/4" | 1 |
| TASB235 | 21" | 23-5/8" | 17-1/4" | 1 |
Standard Sizes With Optional Baffle Kit Installed
| Part No. | Depth | Width | Height | Quantity |
|---|---|---|---|---|
| TASB175SB | 21" | 17-5/8" | 17-1/4" | 1 |
| TASB215SB | 21" | 21-5/8" | 17-1/4" | 1 |
| TASB235SB | 21" | 23-5/8" | 17-1/4" | 1 |
Replacement Filter Dimensions
| Part No. | Filter Dimensions |
|---|---|
| TASB175 | 17.5" x 21" x 1" |
| TASB215 | 21.5" x 21" x 1" |
| TASB235 | 23.5" x 21" x 1" |
