Model AWB14
Wind Load Rated
Aluminum Condensing Unit
Wall-Mount Bracket
Model AWB14
Wind Load Rated Aluminum Condensing Unit Wall-Mount Bracket
Wind Load Rated Aluminum Condensing Unit Wall-Mount Bracket
- Category:Wall-Mount Bracket
- Material:6061 Aluminum
- Max Wind Load Rating:170 psf
- Specification Sheet: Download PDF
- Engineering Drawing: Download PDF
- Purchase: Find Distributors
Product Description
FBC 8th Edition (2023) compliant.
6061-T6 alloy temper aluminum construction.
AWB14-WLR models rated for windload up to 170 psf.
Original raised-seal engineering drawings available at an additional cost.
Optional vibration pad is made from recycled rubber to isolate vibration from condensing unit.
Standard Sizes
| Part No. | Bracket Length | Bracket Spacing | Inner Spacing | Max Unit Size |
|---|---|---|---|---|
| AWB143036-WLR24 | 30" | 24" | 14" | 30" x 30" |
| AWB143636-WLR30 | 36" | 30" | 20" | 38" x 36" |
| AWB144836-WLR36 | 48" | 36" | 26" | 45" x 48" |
